Model

REINFORCED DOOR 83

WANT TO COMPARE THE
DIFFERENT MODELS

COMPARE MODELS
TECHNICAL CHARACTERISTICS

The evolution of the Metalnova security door

DIMENSIONI PERSONALIZZABILI

from 45×190 to 110×250 cm

DIMENSIONI STANDARD

80/85/90×200/210 cm

CHARACTERISTICS

Ambienti interni

Di sicurezza

Burglar-proof: up to Class 4 Burglar-proof class includes all the European rules and regulations established to identify the safety level of armoured doors. They describe all the tests, timing, methods and instruments the door shall resist to.
13 locking points Points where the mobile pistons of the locking side come out to block the door to the frame.
Proteggi cilindro ad incastro con sistema antistrappo Defender in acciaio antitrapano montato da lato esterno della porta a protezione della serratura e del cilindro
Mortise cylinder guard with tear-proof locking system Anti-drill steel defender mounted from the external side of the door to protect the lock and the cylinder.
5 anti-lift bolts Placed on the hinge side of each mobile door, they are cone-shaped and installed to resist to cuts. When the door is closed, they are inserted in the relevant housing in the frame
Self-locking system in case of cylinder forced extraction Locks that, when closed with all the key turns, in case the defender is torn or the cylinder broken, trigger a piston self-blocking system.

Tecniche

Lock with gears This is a lock with a lower noise compared to lever locks, it is very soft to the manual use and it helps the safety cylinder last longer thanks to a significant reduction in friction.
Traditional-type hinges with opening to 180° This hinge is visible from the internal side, it can be adjusted along the two axes and it features a hinge cover matching with the colour of handles.
Aluminium body self-levelling draught excluder The automatic mobile sill drops onto the floor every time the door is shut and, besides reducing draughts significantly, it screens annoying light flashes. The type of mobile sill used varies according to the comfort required and the position of the door, the PVC version improves the thermal transmittance of the product, yet keeping sound quality unvaried.
Double sealing gasket Sealing gasket made from coextruded material with a stiff support that is mounted along the door stop perimeter onto the frame. Always available in the external door stop, it is also available in the internal door stop of the most performing armoured doors.

Prestazionali

Noise reduction: until to 40 dB It is a high level of noise reduction that grants high comfort to homes.
Thermal transmittance: up to 1,25 W/m2k Value connected to the protection from heat and cold, obtained by inserting solid insulating material into the doors of the armoured door.

Ambienti esterni

Di sicurezza

Burglar-proof: up to Class 4 Burglar-proof class includes all the European rules and regulations established to identify the safety level of armoured doors. They describe all the tests, timing, methods and instruments the door shall resist to.
13 locking points Points where the mobile pistons of the locking side come out to block the door to the frame.
Proteggi cilindro ad incastro con sistema antistrappo Defender in acciaio antitrapano montato da lato esterno della porta a protezione della serratura e del cilindro
Mortise cylinder protector with anti-lock-picking system Anti-drill steel defender mounted from the external side of the door to protect the lock and the cylinder.cciaio antitrapano a protezione del cilindro
Self-locking system in case of cylinder forced extraction Locks that, when closed with all the key turns, in case the defender is torn or the cylinder broken, trigger a piston self-blocking system.
5 anti-lift bolts Placed on the hinge side of each mobile door, they are cone-shaped and installed to resist to cuts. When the door is closed, they are inserted in the relevant housing in the frame

Tecniche

Lock with gears This is a lock with a lower noise compared to lever locks, it is very soft to the manual use and it helps the safety cylinder last longer thanks to a significant reduction in friction.
Traditional-type hinges with opening to 180° This hinge is visible from the internal side, it can be adjusted along the two axes and it features a hinge cover matching with the colour of handles.
Aluminium body self-levelling draught excluder The automatic mobile sill drops onto the floor every time the door is shut and, besides reducing draughts significantly, it screens annoying light flashes. The type of mobile sill used varies according to the comfort required and the position of the door, the PVC version improves the thermal transmittance of the product, yet keeping sound quality unvaried.

Prestazionali

Noise reduction: until to 40 db It is a high level of noise reduction that grants high comfort to homes.
Thermal transmittance: until to 1,25 W/m2k Value connected to the protection from heat and cold, obtained by inserting solid insulating material into the doors of the armoured door.
Permeabilità all’aria: Classe 4 Misura certificata di permeabilità all'aria, ottenuta grazie al sistema COMPETITIVE- Consigliato per ingressi da esterno esposti al vento.
Air permeability: Class 4 Air permeability certified measure, obtained thanks to the KIT COMPETITIVE, it is recommended for front doors particularly exposed to wind.
Waterightness: Class A2 Watertightness certified measure, obtained thanks to the KIT COMPETITIVE. It is recommended for front doors particularly exposed to rain.
Resistance to wind: Ndr Resistance to wind certified measure, obtained thanks to the COMPETITIVE system. It is recommended for front doors particularly exposed to wind.

Design

Any finishing can be used with all Metalnova reinforced doors, both internal and external panels, thereby guaranteeing a unique, exclusive design.
